Models
|
Uses
|
Technoloty Dat
|
|
MSV
|
It is suitable in the following process
such as mixing,emulsifying extracting,absorbing,absorbing,reacting
and enforced transforing heat for liquid,liquid with gas
,gas with gas,The vis cosity of mediumis in 102
CPS.
When the hydraulic diamater of mixer is in 3.5mm,it is
suitable to mi the clean medium which is in 102
CPS.
When the hydraulic diamater of mixer is in 5mm,it is suitable
to mix the medium which is mingled with a few non-cohesiveness
medium. |
 ≤1-5％ |
|
MSX
|
It is suitable in the following process
such as mixing,extracting,absorbing for liquid with liquid
with liquid or higher ploymer fluid.When the loading is
large the result will be better. |
≤5 |
|
MSL
MSY
|
It can be applied in chemical petroleum
and oil industry whose viscosities are less than 106
CPS or which are accompanied by high polymer liquid mixture.Operation
units of heat transmission,mixture,heat reatction and
heating or cooling of adherend products are carried out
at the same time. |
≤5％ |
|
MSH
|
It is suitable in the following process
such as mixing,emulsifying, matching colours inject plastic,spinning,transforing
heat in fine chemical industry,plastic industry,synthetic
fibre industry,mining industry.It is special suitable
suitable for mixing clean medium which viscosity is higher.(≤104CPS) |
≤1-5％ |
|
MSK
MSD
|
It is suitable in the following process
such as mixing,extrcating,reacting, absorbing,inject plaslic,matching
colours,transforing heat in chemical industry,petroleum
industry,foodstuff industry,fine chemical industry,plastic
industry,enviromnental potection,synthetic fibre industry,mining
industry,etc.It is special suitable for mixing the high
cohesiveness medium which viscosity is in 106
CPS and mingled with impurity. |
≤5％ |
|
MSJHF
|
It is suitable in the transforing heat
and polyreaction of the high viscosit redium(3000CPS) |
Heat transmission coefficient is 4-5
times than common pipe chain heat-exchanger,and is 2 times
higher than board heat exchanger. |
|
|
